How to Solve Fanuc Spindle Amplifier Module Alarm 12?

MAR. 28, 2025

In a CNC machine shop, the spindle is like the heart of the machine. Once it stops beating, the whole production rhythm will be disrupted. What we are most afraid of in the field is that when the machine tool is processing at full speed, suddenly a line pops up on the screen: “SPINDLE ALM 12”. The machine immediately stops, not only the workpiece scrap, but also let the production line into a deadlock.

Many customers encounter this alarm for the first time will be a little panic: "What does this mean? Is the spindle burned? Should I get a new amplifier right away?" In fact, Alarm 12 means DC circuit overcurrent. Simply put, it means that the current exceeds the safe range, and the system simply stops in order to protect itself.

How to Solve Fanuc Spindle Amplifier Module Alarm 12?

Alarm 12 Common Trigger Causes

We've seen all sorts of things in the repair field, some mechanical problems, some electrical failures. To summarize, there are these general categories:

* Cutting jammed or overloaded: for example, the tool is stuck in the workpiece, the spindle current spiked all of a sudden, the amplifier detects anomalies and reports an error.

* The spindle motor itself is faulty: coil insulation is not good, short circuit, poor grounding, these will trigger overcurrent.

* Internal damage to the amplifier: aging or breakdown of key components such as IPM modules, IGBTs, or capacitors, all of which can trigger Alarm 12.

* Cable or connector problems: loose wires, broken insulation, or even iron filings in the plug can trigger a short circuit.

* Heat dissipation problems: cooling fan is broken, or the heat sink is full of dust, the temperature rises, the circuit is easy to overload.

We have seen a device, the customer because a long time did not clean the air ducts, the fan has long stopped turning, the result is that the amplifier is hot inside the hot, it did not take long to alarm shutdown.

How Do We Usually Investigate

If you encounter Alarm 12, we will not immediately jump to the conclusion that the amplifier is broken, but step by step investigation.

1. First look at the spindle is not jammed -- let the motor idle for a while, if the rotation is easy and smooth, then the probability is not mechanically jammed.

2. Measure the motor -- use megohmmeter to test the insulation, to see if there is no leakage or short circuit.

3. Check the cable -- especially the spindle cable connector, loose, burn marks should be noted.

4. Check the heat dissipation -- the fan does not turn, the heat sink is not blocked.

5. Finally look at the amplifier itself -- if all the previous problems are OK, then the IPM module or IGBT may be really bad.

This kind of troubleshooting process can avoid "misjudgment”. We've had customers who bought a new amplifier, installed it and the problem was still there, but in the end they realized it was actually a shorted motor cable that was frayed. It's a waste of money.

Repair or Replace? Our Experience

This is the step where many customers hesitate: should they repair the amplifier or just replace it?

* If the fan is broken, the capacitor is bulging, or the wires are loose, it is not necessary to replace the module with a brand new one because it can be restored by replacing the parts.

* If the IPM or IGBT is burned out, or the amplifier often reports errors repeatedly, the repair cost and time are higher, so it is more cost-effective to replace it directly.

Once, we helped a mold factory to repair an amplifier, just replace the fan and a few capacitors, the cost is less than one-third of the new parts, the machine immediately recovered. On the contrary, there are customers who dragged their feet and kept on repairing, and as a result, after three repairs, they still reported errors, and finally replaced them with new ones, which not only cost more, but also delayed the production.

The Support We Can Provide

At Songwei, we deal with Fanuc equipment all the time, so whether it's new parts, used parts or repairs, we can help our customers. For example:

* Provide new or used Fanuc spindle amplifier modules, all tested.

* Professional repair and testing services, including IPM, DC bus and other critical parts of the diagnosis.

* Fast shipment to minimize customer downtime.

* Suitable solutions according to the customer's site conditions.

We are more interested in "getting the machine back on line as soon as possible” rather than just selling a part.

Finally

The Alarm 12 alarm on a Fanuc spindle amplifier is essentially current overload protection. It could be a cutting load, a motor or cable failure, internal damage to the amplifier, or a heat dissipation problem.

Our suggestion is: when encountering this kind of alarm, first troubleshoot the mechanical load, then check the motor and cable, confirm that the heat dissipation is normal, and finally determine whether it is the amplifier itself that is at fault.

If it is finally determined that the amplifier is the problem, then it depends on the situation to choose to repair or replace. Don't be in a hurry to shoot the messenger, figure out the cause first to save money and worry.

At Songwei, we're willing to share our repair experience with you because we know too well that every hour of downtime in the workshop costs more than just production.
